3M 3759 Series Flat Cable, Round, 1.27 mm Pitch, 26, 30 m Length
- RS-stocknr.:
- 192-5001
- Fabrikantnummer:
- 3759-26
- Fabrikant:
- 3M
Subtotaal (30 meter, op een rol van 30)*
€ 206,72
(excl. BTW)
€ 250,13
(incl. BTW)
GRATIS bezorging voor bestellingen vanaf € 90,00
Tijdelijk niet op voorraad
- Verzending vanaf 19 november 2026
Heeft u meer nodig? Klik op 'Controleer leverdata' voor extra voorraad en levertijden.
Rol(len) | Per rol | Per meter* |
|---|---|---|
| 1 + | € 206,72 | € 6,891 |
*prijsindicatie
- RS-stocknr.:
- 192-5001
- Fabrikantnummer:
- 3759-26
- Fabrikant:
- 3M
Specificaties
Datasheets
Wetgeving en conformiteit
Productomschrijving
Zoek vergelijkbare producten door een of meer kenmerken te selecteren.
Alles selecteren | Attribuut | Waarde |
|---|---|---|
| Merk | 3M | |
| Product Type | Flat Cable | |
| Cable Type | Round | |
| Pitch | 1.27mm | |
| Voltage | 300V | |
| Screened/Unscreened | Unscreened | |
| Number of Conductors | 26 | |
| American Wire Gauge | 28AWG | |
| Series | 3759 | |
| Conductor Type | Round | |
| Jacket Material | Polyvinyl Chloride | |
| Cable Length | 30m | |
| Standards/Approvals | CL2, FT1, UL, AWM 20267, National Electrical Code Article 725 | |
| Jacket Colour | Black | |
| Hi-Flex | No | |
| Conductor Material | Tin Plated Copper | |
| Maximum Operating Temperature | 80°C | |
| Size of Strands | 36AWG | |
| Core Strands | 7 x 36AWG | |
| Minimum Operating Temperature | -20°C | |
| Number of Strands | 7 | |
| Fire Behaviour | FT1 | |
| Alles selecteren | ||
|---|---|---|
Merk 3M | ||
Product Type Flat Cable | ||
Cable Type Round | ||
Pitch 1.27mm | ||
Voltage 300V | ||
Screened/Unscreened Unscreened | ||
Number of Conductors 26 | ||
American Wire Gauge 28AWG | ||
Series 3759 | ||
Conductor Type Round | ||
Jacket Material Polyvinyl Chloride | ||
Cable Length 30m | ||
Standards/Approvals CL2, FT1, UL, AWM 20267, National Electrical Code Article 725 | ||
Jacket Colour Black | ||
Hi-Flex No | ||
Conductor Material Tin Plated Copper | ||
Maximum Operating Temperature 80°C | ||
Size of Strands 36AWG | ||
Core Strands 7 x 36AWG | ||
Minimum Operating Temperature -20°C | ||
Number of Strands 7 | ||
Fire Behaviour FT1 | ||
- Land van herkomst:
- US
3M 3759 Series Flat Cable, 30m Cable Length, 26 Conductors - 3759-26
This flat cable provides multi-conductor connectivity for low-voltage electronic and automation systems, delivering organised wiring in applications requiring Compact conductor spacing and a flexible jacket. It is intended for installations where a slender profile and consistent conductor arrangement simplify routing and termination.
Features and Benefits:
• 26 conductors with 1.27mm pitch for dense connector layouts
• 28AWG tin-plated copper conductors for corrosion-resistant conductivity
• 7-strand round cores offering improved flexing capability
• PVC jacket rated FT1 for enhanced flame performance
• 300V voltage rating supporting common control circuits
• Unscreened construction reducing weight and cost for non-critical EMI environments
• 28AWG tin-plated copper conductors for corrosion-resistant conductivity
• 7-strand round cores offering improved flexing capability
• PVC jacket rated FT1 for enhanced flame performance
• 300V voltage rating supporting common control circuits
• Unscreened construction reducing weight and cost for non-critical EMI environments
Applications
• Suitable for internal wiring of control cabinets and panels
• Ideal for interconnects between sensor arrays and controllers
• Used with ribbon-style connectors in automation equipment
• Can be used for low-voltage signalling in building services
• Suitable for harnessing in machine tool electronics
• Ideal for interconnects between sensor arrays and controllers
• Used with ribbon-style connectors in automation equipment
• Can be used for low-voltage signalling in building services
• Suitable for harnessing in machine tool electronics
What temperature range can it operate within?
The cable functions across a temperature window from -20°C to 80°C, covering typical indoor industrial environments.
How long is the supplied reel and how does that affect installations?
The cable is provided in 30 m lengths, enabling continuous runs for medium-sized cabinet wiring without frequent joints.
Is the cable suitable for screened applications?
It is unscreened, so it is intended for situations where external electromagnetic shielding is unnecessary or handled separately.
What standards and approvals does it conform to?
It meets CL2 and FT1 classifications and carries AWM 20267 and UL recognition compatible with National Electrical Code Article 725 usage.
What is the conductor geometry and how does that influence termination?
Conductors are round, tin-plated copper with seven strands each, facilitating soldering and crimp terminations while preserving flexibility.
Approvals
UL listed / UL listed for Canada
Warning
These cables are not to be regarded as power cables or cables for the direct connection of equipment to mains power supplies.
