Leica 850273 Cable Detection Transmitter Battery
- RS-stocknr.:
- 230-5093
- Fabrikantnummer:
- 850273
- Fabrikant:
- Leica
Subtotaal (1 eenheid)*
€ 1.255,28
(excl. BTW)
€ 1.518,89
(incl. BTW)
GRATIS bezorging voor bestellingen vanaf € 75,00
Tijdelijk niet op voorraad
- Verzending vanaf 09 februari 2026
Heeft u meer nodig? Klik op 'Controleer leverdata' voor extra voorraad en levertijden.
Aantal stuks | Per stuk |
|---|---|
| 1 + | € 1.255,28 |
*prijsindicatie
- RS-stocknr.:
- 230-5093
- Fabrikantnummer:
- 850273
- Fabrikant:
- Leica
Specificaties
Datasheets
Wetgeving en conformiteit
Productomschrijving
Zoek vergelijkbare producten door een of meer kenmerken te selecteren.
Alles selecteren | Attribuut | Waarde |
|---|---|---|
| Merk | Leica | |
| Product Type | Cable Detection Transmitter | |
| Depth Accuracy | ±5 % | |
| Depth Indicator | Yes | |
| Measurement Mode | Genny | |
| Battery Life | 15h | |
| Battery Type | Lithium-ion | |
| Power Source | Battery | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 50°C | |
| Weight | 2.4kg | |
| Height | 765mm | |
| Width | 290 mm | |
| Length | 93mm | |
| Standards/Approvals | RoHS | |
| Alles selecteren | ||
|---|---|---|
Merk Leica | ||
Product Type Cable Detection Transmitter | ||
Depth Accuracy ±5 % | ||
Depth Indicator Yes | ||
Measurement Mode Genny | ||
Battery Life 15h | ||
Battery Type Lithium-ion | ||
Power Source Battery | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 50°C | ||
Weight 2.4kg | ||
Height 765mm | ||
Width 290 mm | ||
Length 93mm | ||
Standards/Approvals RoHS | ||
- Land van herkomst:
- GB
3 Watt Output Versions
The Leica signal transmitter is a simple, intuitive signal transmitter improving site safety during utility avoidance tasks. Four power level settings and three trace frequencies put you in control improving the detection of utilities. Available in 3 watt version.
Features and benefits
Health Check Extended Self Test Feature
Induction Modes in both 33 & 8 KHz Frequencies
131 Hz Long Distance Trace mode
Adjustable Power output modes
Compact reinforeced plastic case
Li-ion Rechargeable Battery
Longer tracing range
IP67 Waterproof
3 Yr Warranty
Applications
Battery powered signal transmitter used to send frequencies down or along metal structured services in Direct Connection modes
Induce signals by placing the transmitter on the ground over a buried service. Signals are pushed into the ground and onto services
Supplied with/Kit contains:
Li-ion Rechargeable Battery / Charger / Earth Spike / Connection Leads
What other Products are available in this Leica range?
DA230 1 Watt & 3 Watt Versions
Approvals/Certification
Network Rail Approved - UK
