- RS-stocknr.:
- 248-3867
- Fabrikantnummer:
- UBD1005
- Fabrikant:
- Mellor Electric
Bekijk alle DC Motors
10 op voorraad - levertijd is 1 werkdag(en) (EU-voorraad)
33 op voorraad - levertijd is 3 à 5 werkdagen (UK-voorraad)
Prijs Each
83,32 €
(excl. BTW)
100,82 €
(incl. BTW)
Aantal stuks | Per stuk |
1 - 2 | 83,32 € |
3 - 4 | 80,82 € |
5 + | 78,31 € |
- RS-stocknr.:
- 248-3867
- Fabrikantnummer:
- UBD1005
- Fabrikant:
- Mellor Electric
Datasheets
Wetgeving en conformiteit
- Land van herkomst:
- GB
Productomschrijving
Mellor Electrics 24Vdc Geared Motor, Series UBD
UBD1000 Series Geared Motor
Geared Motor
24 Vdc rated voltage
Low speed, high torque
Note
This gear reduction unit has fitted a dc motor stock no. 248-3671 to give the final output speeds listed below
Specificaties
Kenmerk | Waarde |
Supply Voltage | 24 V dc |
DC Motor Type | Geared |
Output Speed | 160 rpm |
Shaft Diameter | 8mm |
Maximum Output Torque | 2 Nm |
Gearhead Type | Spur |
Core Construction | Iron Core |
