Real Time Clocks

What is a Real Time Clock?

A Real Time Clock (RTC) is a computer clock which is usually in the form of an integrated circuit. They have been designed to keep track of time, in real time - hence the product name. A Real Time Clock is usually an integral part of the computer motherboard. More often than not, an RTC will also include a calendar and an alarm

How do Real Time Clocks work?

The memory on the clocks system stores system descriptions and set up values such as "Current Time Value". The information that is held in the RTC is read with a microprocessor, commonly over a serial interface which facilitates the performance of the software functions that are time dependant.

Designed to run on ultra-low power consumption, RTCs often run on a lithium battery source but can also run on normal power. This power source allows them to continue running and generating real time when a system is down. The newer models of RTC use super-capacitors as a source of power that can be recharged and soldered to the board. Some Real Time Clocks feature synchronisation to an external signal, such as a compensated power line frequency. It allows the device to provide an accurate result without having an on-board temperature compensation scheme.

RTC Time Values

  • Year
  • Month
  • Date
  • Hours
  • Minutes
  • Seconds

...
Lees meer Lees minder

Filters

1 - 20 van 434 producten worden weergegeven
Resultaten per pagina
Omschrijving Prijs Functions Date Format Time Format User RAM Bus Type Mounting Type Package Type Pin Count Dimensions Length Width Height Maximum Operating Supply Voltage Maximum Operating Temperature
RS-stocknr. 124-2362
FabrikantnummerPCF8563T/5,518
FabrikantNXP
0,658 €
Each (On a Reel of 2500)
Aantal stuks
Calendar, Clock YY:MM:DD:dd HH:MM:SS - Serial-2 Wire, Serial-I2C Surface Mount SOIC 8 5 x 4 x 1.45mm 5mm 4mm 1.45mm 5.5 V +85 °C
RS-stocknr. 165-5486
FabrikantnummerM41T83SQA6F
1,449 €
Each (On a Reel of 1000)
Aantal stuks
Real Time Clock DW:DM:M:Y HH:MM:SS:hh 32B Serial-2 Wire, Serial-I2C Surface Mount QFN 16 4.1 x 4.1 x 0.95mm 4.1mm 4.1mm 0.95mm 5.5 V +85 °C
RS-stocknr. 865-2208
FabrikantnummerPCF8563T/5,518
FabrikantNXP
0,683 €
Each (In a Pack of 10)
Aantal stuks
Calendar, Clock YY:MM:DD:dd HH:MM:SS - Serial-2 Wire, Serial-I2C Surface Mount SOIC 8 5 x 4 x 1.45mm 5mm 4mm 1.45mm 5.5 V +85 °C
RS-stocknr. 714-7288
FabrikantnummerM41T56M6F
2,285 €
Each (In a Pack of 2)
Aantal stuks
Calendar, Chip Deselect, Switch Over DW:DM:M:Y HH:MM:SS 64B Serial-I2C Surface Mount SOIC 8 4.9 x 3.9 x 1.25mm 4.9mm 3.9mm 1.25mm 5.5 V +85 °C
RS-stocknr. 103-1580
FabrikantnummerM41T56M6F
1,144 €
Each (On a Reel of 2500)
Aantal stuks
Calendar, Chip Deselect, Switch Over DW:DM:M:Y HH:MM:SS 64B Serial-I2C Surface Mount SOIC 8 4.9 x 3.9 x 1.25mm 4.9mm 3.9mm 1.25mm 5.5 V +85 °C
RS-stocknr. 877-2781
FabrikantnummerM41T83SQA6F
2,74 €
Each (In a Pack of 5)
Aantal stuks
Real Time Clock DW:DM:M:Y HH:MM:SS:hh 32B Serial-2 Wire, Serial-I2C Surface Mount QFN 16 4.1 x 4.1 x 0.95mm 4.1mm 4.1mm 0.95mm 5.5 V +85 °C
RS-stocknr. 729-3215
FabrikantnummerRV-3029-C2-TA-006
FabrikantMicro Crystal
11,54 €
Each
Aantal stuks
Battery Backup, Calendar, RAM DW:DM:M:Y HH:MM:SS 8B Serial-I2C Surface Mount SON 10 5 x 3.2 x 1.2mm 5mm 3.2mm 1.2mm 5.5 V +85 °C
RS-stocknr. 511-103
FabrikantnummerPCF8563TS/4,118
FabrikantNXP
1,39 €
Each (In a Pack of 5)
Aantal stuks
Alarm, Battery Backup, Calendar, Watchdog Timer DW:DM:M:Y HH:MM:SS - Serial-I2C Surface Mount TSSOP 8 3.1 x 3.1 x 0.95mm 3.1mm 3.1mm 0.95mm 5.5 V +85 °C
RS-stocknr. 662-4722
FabrikantnummerBQ4802LYPW
3,16 €
Each
Aantal stuks
Alarm, Battery Backup, Calendar, NV SRAM DW:DM:M:Y HH:MM:SS 16B Parallel Surface Mount TSSOP 28 9.7 x 4.4 x 1.15mm 9.7mm 4.4mm 1.15mm 3.6 V +70 °C
RS-stocknr. 880-5345
FabrikantnummerM41T94MH6F
5,265 €
Each (In a Pack of 6)
Aantal stuks
Alarm, Battery Backup, Interrupt, NVRAM, Real Time Clock, Watchdog Timer Binary, D:D:M:Y:C Binary, HH:MM:SS 44B Serial-SPI Surface Mount SOH 28 18.49 x 8.89 x 2.69mm 18.49mm 8.89mm 2.69mm 5.5 V +85 °C
RS-stocknr. 624-8466
FabrikantnummerM48T35Y-70PC1
22,29 €
Each
Aantal stuks
Battery Backup, Calendar, Chip Deselect, Switch Over, Write Protection DW:DM:M:Y HH:MM:SS 32768B Parallel Through Hole PCDIP 28 39.88 x 18.34 x 8.89mm 39.88mm 18.34mm 8.89mm 5.5 V +70 °C
RS-stocknr. 165-5508
FabrikantnummerM41T94MH6F
2,774 €
Each (On a Reel of 936)
Aantal stuks
Alarm, Battery Backup, Interrupt, NVRAM, Real Time Clock, Watchdog Timer Binary, D:D:M:Y:C Binary, HH:MM:SS 44B Serial-SPI Surface Mount SOH 28 18.49 x 8.89 x 2.69mm 18.49mm 8.89mm 2.69mm 5.5 V +85 °C
RS-stocknr. 166-1602
FabrikantnummerPCF8563TS/4,118
FabrikantNXP
0,973 €
Each (On a Reel of 2500)
Aantal stuks
Alarm, Battery Backup, Calendar, Watchdog Timer DW:DM:M:Y HH:MM:SS - Serial-I2C Surface Mount TSSOP 8 3.1 x 3.1 x 0.95mm 3.1mm 3.1mm 0.95mm 5.5 V +85 °C
RS-stocknr. 162-6913
FabrikantnummerBQ4802LYPW
3,135 €
Each (In a Tube of 50)
Aantal stuks
Alarm, Battery Backup, Calendar, NV SRAM DW:DM:M:Y HH:MM:SS 16B Parallel Surface Mount TSSOP 28 9.7 x 4.4 x 1.15mm 9.7mm 4.4mm 1.15mm 3.6 V +70 °C
RS-stocknr. 171-1639
FabrikantnummerRV-3029-C2-TA-006
FabrikantMicro Crystal
7,109 €
Each (On a Tape of 100)
Aantal stuks
Battery Backup, Calendar, RAM DW:DM:M:Y HH:MM:SS 8B Serial-I2C Surface Mount SON 10 5 x 3.2 x 1.2mm 5mm 3.2mm 1.2mm 5.5 V +85 °C
RS-stocknr. 920-9001
FabrikantnummerM48T35Y-70PC1
19,961 €
Each (In a Tube of 12)
Aantal stuks
Battery Backup, Calendar, Chip Deselect, Switch Over, Write Protection DW:DM:M:Y HH:MM:SS 32768B Parallel Through Hole PCDIP 28 39.88 x 18.34 x 8.89mm 39.88mm 18.34mm 8.89mm 5.5 V +70 °C
RS-stocknr. 165-2099
FabrikantnummerMCP79510-I/MS
FabrikantMicrochip
0,858 €
Each (In a Tube of 100)
Aantal stuks
Calendar DW:M:Y:LY HH:MM:SS:HSS 64B Serial-SPI Surface Mount MSOP 10 3 x 3 x 0.95mm 3mm 3mm 0.95mm 3.6 V +85 °C
RS-stocknr. 189-8414
FabrikantnummerDS1306EN+
FabrikantMaxim Integrated
5,065 €
Each (In a Pack of 2)
Aantal stuks
Battery Backup, Calendar, NV RAM DW:DM:M:Y HH:MM:SS 96B Serial-SPI Surface Mount TSSOP 20 6.6 x 4.5 x 0.95mm 6.6mm 4.5mm 0.95mm 5.5 V +85 °C
RS-stocknr. 189-8627
FabrikantnummerDS1306+
FabrikantMaxim Integrated
5,125 €
Each (In a Pack of 2)
Aantal stuks
Alarm, Battery Backup, Calendar DW:DM:M:Y HH:MM:SS 96B Serial-SPI Through Hole PDIP 16 19.43 x 7.87 x 4.45mm 19.43mm 7.87mm 4.45mm 5.5 V +70 °C
RS-stocknr. 921-5532
FabrikantnummerCDP68HC68T1MZ
10,23 €
Each
Aantal stuks
Alarm, Battery Backup, Calendar, Watchdog Timer DW:DM:M:Y HH:MM:SS 32B Serial-SPI Surface Mount SOIC W 20 13 x 7.6 x 2.35mm 13mm 7.6mm 2.35mm 6 V +85 °C
